On Tuesday morning, surfers once again witnessed surfing's own natural wonder - Teahupo'o in full flight. And this time it happened with the eyes of the world also watching.
Among the Olympic viewership, surfers needn't be reminded about how remarkable Teahupo'o is; for over twenty years we've watched and wondered about this incredible wave.
Yet despite many attempts, no-one has explained why it does what it does. Occasionally a commentator might remark about the deep channel abutting the wave, surmising that its depth is what causes Teahupo'o to fall over itself in perfect fashion.
Anyone who's spent much time in the tropics knows that's an inadequate answer. Where coral grows it's not unusual to have a deepwater pass nearby - sometimes formed by freshwater run-off from mountains, other times by water escaping fringing lagoons.
The question is this: Why, if there are a million coral reefs in the tropics, is there only one Teahupo'o?
The proximity of deepwater may be part of the answer yet there's much more to learn.
Like the rest of us, Tom Shand has wondered about Teahupo'o, however Tom's also a coastal engineer and a wave scientist, meaning he has the means to peer a bit deeper into the mystery of Chopes.
As a set approaches the reef at Teahupo'o, the ocean appears to rise up before Jack Robinson who salutes the specatacle (ISA/Jiminez)
To understand why Teahupo'o breaks as it does, we need to start with bathymetry: the shape of the seabed that influences waves as they approach the shore. At Teahupo'o, a combination of factors comes into play.
Waves arriving at Teahupo'o generally originate from intense Roaring Forties storm systems south of New Zealand. By the time the waves reach Tahiti they have become ordered swell, with periods of 14 to 20 seconds.
These types of long-period waves normally start interacting with the seabed at depths of around 200 metres. On most coasts, this depth would occur several hundred metres to a few kilometres offshore. But at Teahupo'o, it is much closer, just a couple of hundred metres off the reef.
This rapid change in depth forces the wave to shoal very quickly – the wave speed slows, the distance between waves compresses, and the wave height increases.
The change is so abrupt that the wave is still very linear – it hasn’t had time to develop the peaked crest and flat trough typical of waves in shallow water.
Waves breaking on a slope this steep would typically collapse - breaking from the middle of the wave and creating a steppy, unsurfable mess. But at Teahupo'o this doesn’t happen.
Crucially for our understanding of Teahupo'o, at around ten metres depth a flatter shelf in the reef allows the wave to stabilise and 'stand up' with a steep front face, before finally breaking as the reef rises yet again.
And break it does. Owing to the linearity, there is far more water in the crest than most waves, and a deeper trough in front.
This makes for the characteristic extra-thick plunging lip into a trough well below sea level, compressing a lot of air that is forced (spat) out of the wave’s barrel after breaking.
Critically, the larger the wave, the closer to the steep offshore ramp it breaks, and the more extreme the plunging.
Location and bathymetry of of Teahupo'o (elevation data from SHOM, satellite imagery from Airbus)
A range of other unique features contribute to the way the wave breaks at Teahupo’o.
A deep channel runs alongside the shallow reef shelf. The wave doesn’t break in this deeper area, allowing it to peel before it finally closes out onto shallow reef.
A part of the shallow reef platform extends offshore, into the reef pass. This shallow area bends and focuses wave energy from the wider, deeper part of the wave back into the breaking wave. This happens particularly on more westerly-orientated swells, increasing the intensity of breaking and forming the west bowl.
As well as this, the orientation of the wave at Teahupo'o is cross-offshore to the prevailing southeast trade winds, keeping the wave face smooth.
A low tidal range also limits the times the reef is too deep or too shallow to surf. And the wave is near the Passa Hava'e reef pass, which helps the wave’s focusing and breaking. But because it isn’t right in the pass, the wave isn’t affected by high tidal or wave-induced currents.
Celeris wave model simulating typical surfing conditions at Teahupo’o (Elevation data from SHOM, satellite imagery from Airbus, wave model by Celeria Labs)
New-generation wave models that simulate individual waves, rather than just average energy density, provide insight into what creates a surf break such as Teahupo'o (see video above) These models provide insight into what happens as waves shoal and refract (bend and focus) over the seabed as they approach break point.
They also significantly improve our understanding of what makes a particular surf break unique. This can help in assessing the potential impact of human or natural modifications to the environment.
// TOM SHAND
